LV516302 Schneider Electric Molded Case circuit breaker EasyPact CVS160B, 25 kA at 415 VAC, 125 A rating thermal magnetic TM-D trip unit, 3P 3d
Original price was: 8,201.00 EGP.8,100.00 EGPCurrent price is: 8,100.00 EGP.
Molded Case Circuit Breaker
LV516302
| Quantity | Price | Discount |
|---|---|---|
| 10-20 | 7,938.00 EGP | 2% |
| 21-100 | 7,695.00 EGP | 5% |
| 101-200 | 7,492.50 EGP | 7.5% |
| 201+ | 7,290.00 EGP | 10% |
3 in stock (can be backordered)
LV516302 Schneider Electric Molded Case circuit breaker EasyPact CVS160B, 25 kA at 415 VAC, 125 A rating thermal magnetic TM-D trip unit, 3P 3d
EasyPact CVS160B is a 3 poles 3d fixed circuit breaker with a high level of performance and cost-saving functionality. It is an optimal choice for small and medium-sized buildings protection applications. The breaking capacity (Icu) is 25kA rms at 415VAC 50/60Hz. The operational voltage is 440VAC 50/60Hz. This product embeds a 125A rating thermal-magnetic trip unit (TMD). TMD trip unit provides an adjustable thermal overload protection and a fixed magnetic protection. This 3 poles version (105mm x 161mm x 86mm) comes with a variety of optional functions and accessories. EasyPact CVS160B is compliant with international standards (IEC 60947, CCC, EAC). It can be installed in class II insulation switchboards as it is a class II front face device (IEC 60664-1).
Datasheet:
| Shipping Weight | 2 kg |
|---|---|
| Brand | Schneider Electric |
| Series | EasyPact |
| Model | LV516302 |
| Poles description | 3P |
| [In] rated current | 125 A at 40 °C |
| Network type | AC |
| [Icu] Breaking capacity | 40 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 25 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 20 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 |
