SDR-480-48 Mean Well Power Supply Din Rail 48 VDC 10A
8.200,00 EGP
Power Supply
48VDC 10A
| Quantity | Price | Discount |
|---|---|---|
| 10-20 | 8.036,00 EGP | 2% |
| 21-100 | 7.790,00 EGP | 5% |
| 101+ | 7.380,00 EGP | 10% |
Available on backorder
Description
SDR-480-48 Mean Well Power Supply Din Rail 48 VDC 10A
Brand: Mean Well
Model: SDR-480-48
output: 48 VDC 10A
Metal case, slim size
1∅, full range input (230VAC only for SDR-960)
94% high efficiency and complete functions
Built-in active PFC function (except SDR-75)
Built-in DC OK relay contact (except SDR-75)
Datasheet:
Specifications
| Shipping Weight | 2,2 kg |
|---|---|
| Brand |
Mean Well |
| Series |
SDR |
| Model |
SDR-480-48 |
| TECHNOLOGY |
AC/DC |
| INPUT VOLTAGE (VAC) |
90~264 |
| OUTPUT VOLTAGE (VDC) |
48 |
| OUTPUT CURRENT (A) |
10A |
| OUTPUT POWER (W) |
480 |
| SHAPE |
Din Rail |
| PRODUCT DIMENSION (LXWXH) (MM) |
85.5×125.2×128.5 |
| PRODUCT WEIGHT (KG) |
1.72 |
| IP RATING |
not assigned |
| ROHS |
ROHS |
| SAFETY |
BSMI ,CB ,CE ,CUL listed ,EAC ,GL ,TUV-62368-1 |
Datasheet
